Customize Bosean Fixed Gas Detector , Quick Response Ammonia Gas Monitor

Name: Customize Bosean Fixed Gas Detector Quick Response Ammonia Gas Monitor
Brand: Bosean
Price: 1 USD

China Customize Bosean Fixed Gas Detector , Quick Response Ammonia Gas Monitor wholesale

Brand Name : Bosean

Model Number : bh-60

Certification : CE,FCC,ATEX,ROHS,SIL

Place of Origin : Zhengzhou,Henan,China

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000PCS/DAY

Delivery Time : 3-8 WORK DAYS

Packaging Details : each set detector alarm will be packed with the export standard carton package or aluminum box or as per customer require

Product Name : Fixed H2s Gas Detector

Working Voltage : 15~30VDC

Sampling : Diffusion

Sensor : Catalytic Sensor or Imported British Sensor

Safe Degree : Intrinsically Safe

Response Time : <30s

Output Signal : 4-20mA/RS485

Indication : LED

Contact Now

Bosean Good Quality Quick response China Ammonia Fixed Ammonia Gas Detector

Description

BH-60 fixed gas detector can continuousely detect the concentration of toxic gases, flammable gases, Oxygen.

It is widely used in metallurgy, petrol, petrifaction, chemistry, light industry, coking, municipal administration, gas, pharmacy, sewage dealing and many other special industries and fields.

Standard 4~20mA two wires signal output. It can transfer data in long distance, can get into the DSC system directly.

Parameters

Product type	BH-60 fixed gas detector
Response time	<30S
Power supply	DC24V±10%
Working temperature	-20ºC~50ºC
Output current	4-20mA
Working humidity	0-95%RH (no dew)
Contact output	Free contact output, max power 1kW
Single input	4~20mA and RS485
Installation method	Wall-mounted
Shell material	Aluminum
Dimensions	19015095mm(LWH)
Weight	≤ 1.6kg

Main Features

The detector working with gas controller can be used to detect gas in refinery, chemical plant, LPG station, boiler room, painting plant and other places with gas exists.
4-20mA or RS485 output optional
EX certificate

Application

Customize Bosean Fixed Gas Detector , Quick Response Ammonia Gas Monitor

Our customers and patent certificate

Customize Bosean Fixed Gas Detector , Quick Response Ammonia Gas Monitor

Measurable Gas Meter

No	Detecting Gas	Gas	Measure Range	Resolution	Alarm Point (High / Low)
1	Combustible Gas	EX	0-100%LEL /0-100%VOL	1%LEL/1%VOL	20 / 50% LEL
2	Oxygen	O2	0-25% /30%VOL	0.1%VOL	19.5% / 23.5%VOL
3	Hydrogen Sulfide	H2S	0-50/100/200/1000 ppm	0.1 ppm	10 / 20 ppm
4	Carbon Monoxide	CO	0-500/1000/2000/5000 ppm	1 ppm	50 / 150 ppm
5	Nitrogen Dioxide	NO2	0-20/50/1000 ppm	0.1 ppm	5 / 10 ppm
6	Nitric Oxide	NO	0-250/500/1000 ppm	1 ppm	50 / 150 ppm
7	Carbon Dioxide	CO2	0-5000 ppm /0-1%/5%/10%VOL	1 ppm/0.1%VOL	1000 /2000 ppm
8	Sulfur Dioxide	SO2	0-20/50/100/200/1000 ppm	0.1 /1 ppm	5 / 10 ppm
9	Chlorine	CL2	0-20/100/1000 ppm	0.1 ppm	5 / 10 ppm
10	Ammonia	NH3	0-50/100/500/1000 ppm	0.1 ppm	20 / 50 ppm
11	Hydrogen	H2	0-1000/5000 ppm	1 ppm	50 /150 ppm
12	Phosphine	PH3	0-5/20/50/100/500/1000 ppm	0.1 ppm	5 / 10 ppm
13	Hydrogen Chloride	HCL	0-20/500/1000 ppm	0.01/0.1 ppm	5 / 10 ppm
14	Chlorine Dioxide	CLO2	0-10/50/100 ppm	0.1 ppm	5 / 10 ppm
15	Hydrogen Cyanide	HCN	0-50/100 ppm	0.01/0.1 ppm	10 / 20 ppm
16	Ethylene Oxide	C2H4O	0-10/20/50/100/200/500 ppm	0.1 /1 ppm	20 / 50 ppm
17	Ozone	O3	0-10/20/100 ppm	0.1 ppm	2 / 5 ppm
18	Formaldehyde	CH2O	0-20/50/100 ppm	0.1 /1 ppm	5 / 10 ppm
19	Hydrogen Fluoride	HF	0-1/10/50/100 ppm	0.01 /0.1 ppm	2 / 5 ppm
20	Methylbenzene		0-1/10/20/50/100 ppm	0.01 /0.1 ppm	5 / 10 ppm

Note: The above table is a general parameter. If you need other gas and range, please contact our online customer service.
